SSS-5 Series Automatic Swing Door Safety Sensors EN16005 Compliant

Designed for EN16005 compliance, each PCB unit delivers 6 spots of detection, achieving up to a 900mm wide safety curtain per unit—ideal for low-level safety near the floor.

The sensors are mounted at the top of the door leaf, one one each side, to provide both opening and closing safety. When the sensor detects an obstacle, the relay switches which sends a signal to the door operator to stop or prevent the movement, thereby avoiding injury or damage.

Key Features:

• Enhanced Safety: 6 detection spots per unit for superior pedestrian safety.
• Custom Lengths: Available in 3 different lengths to suit various door sizes.
• Wide Coverage: Just 1 PCB unit needed for a full 900mm safety curtain.
• Low-Level Detection: Adjustable to monitor zones close to the floor.
• Real-Time Adaptation: Automatically adjusts to changing environmental conditions.
• Easy Setup: Simple push-button configuration and removable terminal block.
• Connectivity: Includes cable for communication between sensors on both door sides.
• Durable Design: Robust housing resists damage during installation and operation.
• Maintenance-Free: Long-lasting performance with no upkeep required.

Perfect for public buildings, commercial facilities, and anywhere pedestrian door safety is a priority.

Maximise Pedestrian Safety

Only 1 PCB unit is required to provide 800 - 1,000mm of safety coverage along the swing door width

Save on Costs

No need to use 2 PCB units in one sensor housing to ensure compliance with EN16005

Reduce Installation Times

Removable wiring terminal block and push button detection distance settings significantly reduces on-site installation time.

Strong & Robust

Solid, tough sensor body design not susceptible to vandalism or damage during installation

Performance Reliability

The SSS-5 performs reliably on all floor surfaces and reflective environments

• Detection Method: Infrared Presence Detection with P.S.D. distance measurement
• Installation Height: 2600mm (8.5ft) Max
• Sensor Dimensions:
  • SSS-5S1: 360mm (W), 45mm (H), 45mm (D)
  • SSS-5M1: 692mm (W), 45mm (H), 45mm (D)
  • SSS-5L1: 1,023mm (W), 45mm (H), 45mm (D)
• Pattern Adjustment:
  • Beam Angle Adjustment: 5, 10, 15, 20, 25 degrees
  • Detection Distance Adjustment: Dead Zone, 50-500mm
• Detection Range: 0 - 2.5m (0 - 8ft 2 inches)
• Presence Timer: Infinity
• IP Rating: 54
• Power Supply: 12 to 24V AC or DC ± 10%
• Power Consumption:
  • AC12V-1.7 [VA] (Max), DC12V-95 [mA]
  • AC24V-2.3 [VA] (Max), DC24V-55 [mA]
• Output Relay: Relay contact: DC50V 0.1A Non Voltage 1C
• Response Speed: Less than 100 msec
• Relay Hold Time: 0.5 sec
• DIP Switch Functions:
  • Test Input
  • Optical Interference
  • Relay Output Mode
  • Masking Detection Spots
  • Detection Range
• Operating Temperature: -20°C to +60°C, (-4°F to 140°F)
