Our automatic door square push button style sensor offers a sleek, touch free way to activate automatic doors, access control systems and other switching applications. Built with a 316 marine grade stainless steel label, it combines modern design with exceptional durability, making it ideal for both internal and external installations.

Unlike traditional push pads, this sensor requires no physical pressure to operate, just a simple wave or light touch. That makes it perfect for users with physical disabilities. The adjustable sensitivity, audible beep, and selectable LED illumination provide reassuring feedback, while the bold signage supports users with visual or hearing impairments.

Hygienic and Reliable

Touch free operation helps reduce the spread of germs and infections, creating safer environments for everyone. Bacteria can survive on hands for up to three hours, and with around 80% of contagious diseases transmitted by touch, our no-touch sensors are a smart, hygienic alternative to conventional push pads and hospital switches.

Why Choose Our Sensors

DDA Compliant and fully accessible
Illuminated LED options for visual clarity
Adjustable sensitivity to suit your installation
Available in a range of styles and finishes
Ideal for automatic doors, toilet doors and access control systems
Custom signage available, including company name and logo
Suitable for internal and external use (except single gang)
Reliable, modern and robust
More cost effective than traditional stainless steel mechanical pads

Please Note: Our stainless steel sensors are slowly being phased out. We have developed an advanced “faux” stainless steel range, offering improved hygiene and enhanced durability.

DDA Compliant
12 – 28Vdc
4 position sensitivity adjustment. (Touch up to 50mm hands free)
Timed clean relay output
Selectable red, blue & green LED’s
Sounder on activation
Marine grade 316 stainless steel label
Entire label is sensitive
Reinforced nylon housing
IP54 rated

Company name & logo can be printed on the label (Contact us for further information)

📄Datasheet

📄TOUCH SENSOR MANUAL

🔹0V switching operators

🔹+V switching operators

🔹Record DFA127

🔹Label NEXT120S

🔹Gilgen FD10 & FD20

◾ Touch sensor doesn’t beep/activate when touched

Step-by-step checks: After each step below, de-power the system for 10 seconds and power it back up.

Screw the sensor to the wall properly, don’t have it dangling or in your hand.
Change the sensitivity.
Ensure the jumper next to the touch sensor relay is on and is making properly.
Make sure 0V is in the correct terminal, not the REM terminal.
Use a multimeter to check you’ve got voltage at the touch sensor (+V Red & 0V black).
Take off the wall and connect power directly to the power supply on a short piece of cable to rule out any cable issues or short circuits.

◾ Touch sensor activates randomly

Solution:

Turn down the sensitivity on the touch sensor, especially if there is emergency lighting nearby.
Make sure there isn’t excess cable in the back box.
Re-terminate all connections.
Touch sensors can be activated by changes in voltage which is a problem on unregulated power supplies. Fit a separate transformer.
