CPK7 Waterproof Gate Entry Kit
SKU:
CPK7
Categories:
Gate Access Kits, Access Control, Door & Gate Entry Keypads, Proximity & Biometrics, Gate Access Kits, Gates & Barriers, Standalone Door Access Kits
£165.55 EX VAT
Waterproof access control gate entry kit.
What is Included?
- 1 x KPS keypad & reader
- 1 x PSU 12V 1amp Power Supply
- 1 x CP500W Waterproof Mag lock. 1200lbs holding force
- 1 x CP500WZL Z&L bracket
- 1 x WP-EBGBWC02/PTE Door release button
- 1 x 12V 2.3ah battery
- 5 x proximity fobs
All parts are waterproof, except the power supply & battery. This must be situated indoors or in a suitable housing.
Everything you need in one box!
PFOB-G + (Price £0.88 EX VAT per item)
MCP440-WP + (Price £60.00 EX VAT per item)
Additional information
| Weight | 7 kg |
KPS:
- Operating voltage 12-28Vac/dc
- Waterproof, conforms to IP66
- One relay output
- Strong anti-vandal zinc alloy powder coated housing
- Full programming from the keypad
- Admin add/delete cards for quick programming of card users
- 1000 users, supports card, PIN, or card + PIN
- Card frequency 125KHz EM
- PIN length 4-6 digits
- Backlit keys
- Wiegand 26-37 bits input & output
- Tri colour LED status display
- Integrated alarm and buzzer output
- Pulse (adjustable) or toggle mode
- User data can be transferred to other units
- Built in light dependent resistor (LDR) for anti-tamper
- Pre-wired 1 metre cable
- Dimensions: 114.5 x 75 x 22mm
Power supply:
- 12V 1A output
- Lockable metal box
- Battery charging circuit
- 195 x 80 x 225mm
CP500W:
- Lock Size: 222Lx62Wx38H(mm)
- Armature plate: 195Lx61Wx15H(mm)
- Holding Force: 500kg (1200Lbs)
- IP68 rated
WP-EBGBWC02-PTE:
- All plastic large green button.
- Momentary operation.
- Wear resistant legend.
- IP66 Rated
- Dimensions:Â 85x85x40/50 (mm)
- 2 year warranty on the keypad.
- 1 year warranty on all other items.
