CPK8 Waterproof Gate Entry System
£164.48 ex VAT
Secure your manual swing gate with this waterproof access control gate entry system.
Only authorised users with a valid proximity card, fob or PIN code can unlock the gate and push or pull it open. When they’ve gained access, the gate automatically locks again after a pre-set amount of time (a closer should be fitted). Users can be easily added or deleted by the manager of the system using the supplied master cards or via the keypad.
Free exit using the push button. A waterproof break glass (MCP440-WP) can be supplied as an optional extra.
What is Included?
- 1 x KPN – Easy to program narrow style keypad & proximity reader. Ideal for mounting on a post or wall.
- 1 x PSU-BB-12V-1A – Power supply in metal lockable box.
- 1 x CP500W – Waterproof mag lock. 1200lbs holding force.
- 1 x CP500WZL – Z&L bracket for easy installation of mag lock.
- 1 x WP-EBGBWC02/PTE Press to Exit green dome lock release button
- 1 x BATT2.1 12v 2.1ah battery – Ensures the gate remains locked during power outages
- 5 x PFOB-G Proximity fobs
Everything you need in one box! Add a waterproof break glass as an add on if required.
Important installation note: All parts are waterproof, except the power supply & battery. This must be situated indoors or in a suitable IP rated housing.
Have you got custom access control requirements? Or would you like more information on our gate locking systems? Please contact our team to discuss.
- Operating voltage 12-28Vac/dc
- Waterproof, conforms to IP66
- One relay output
- Strong anti-vandal zinc alloy powder coated housing
- Full programming from the keypad
- Admin add/delete cards for quick programming of users
- 1000 users, supports card, PIN, or card + PIN
- Card frequency 125KHz EM
- PIN length 4-6 digits
- All metal backlit keys
- Wiegand 26-37 bits input & output, connect slave reader or to a controller
- Tri colour LED status display
- Integrated buzzer and alarm output
- Pulse (adjustable) or toggle mode
- User data can be transferred to other units
- Built in light dependent resistor (LDR) for antitamper
- Pre-wired 1 metre cable
- Dimensions: 134 x 55 x 21mm
- 12V 1A output
- Lockable metal box
- Battery charging circuit
- 195 x 80 x 225mm
- Lock Size: 222Lx62Wx38H(mm)
- Armature plate: 195Lx61Wx15H(mm)
- Holding Force: 500kg (1200Lbs)
- IP68 rated
- All plastic large green button.
- Momentary operation.
- Wear resistant legend.
- IP66 Rated
- Dimensions:Â 85x85x40/50 (mm)
- 2 year warranty on the keypad/reader.
- 1 year warranty on all other items.
| Weight | 7 kg |
|---|
