HDOOREVO+CP5-RX KIT Receiver with Wiegand Keypad & Reader
£233.58 ex VAT
Web Based Access Control System – Real Time Remote Management
The HDOOREVO real-time access control system offers all the features of the HONOADOOR receiver, with additional support for Motion and Wiegand proximity readers and keypads. This enables real-time management of transmitters, proximity tags, cards, and PIN codes via the JCM CloudAssistant web portal.
This kit includes the CP5-RX Wiegand proximity reader and keypad, which reads EM, HID, and Mifare cards and tags, ensuring broad compatibility.
Key Features:
Remote System Management
- Connects to the internet wirelessly via WiFi or SIM card
- Great alternative to traditional networked access control
- Add and delete transmitters, cards, tags, and keypad codes from anywhere
- View event logs and access history in real time
- Monitor door or gate status (requires door contact)
- Remotely activate relays without visiting site
- Configure access groups and user schedules
- Set validity periods and block or unblock users individually (paid feature for Wiegand devices, £3 per year per HDOOREVO)
Universal Compatibility
- Compatible with any access control panel or electric lock
- CP5-RX reader supports EM, HID, and Mifare credentials
- Supports both long-range transmitters and proximity-based access
Easy Installation & Setup
- All configuration can be done off-site before installation
- No on-site programming required
- Sequential programming allows hundreds of users to be added quickly
- Minimal cabling required, no network cabling thanks to wireless connection
Low Maintenance, No SIM Subscriptions
- Supplied with a 10-year data SIM (no monthly charges)
- Optional mobile app with hands-free opening feature (license required, £10 per user for 5 years)
This system is ideal for car parks, residential gates, commercial properties, and other sites where secure, flexible, and remotely managed access control is required.
To discuss this product in more detail, or system options, please contact us. Our team is happy to assist with technical guidance, project specs, or custom requirements.
- Power supply: The equipment is powered with a 110Vac to 230Vac voltage. 500mA protective fuse.
- Relay Output: The equipment has 2 adjustable open or closed contact relay outputs. These outputs can be programmed to be activated with different fob channels through cloudAssistant. Moreover, these relays can be remotely activated in real time with the cloudAssistant.
- Inputs: The equipment has 2 inputs to connect 2 limit switches or door contacts to monitor the door’s status (Open/Closed).
- 868MHz MOTION receiver module: The equipment has an 868MHz MOTION receiver module to receive from fobs, up to 100 metre range.
- Extension module for wired keyboards and readers: the device includes two "Wiegand" inputs, a "Wiegand" output, and a "BUS-L" input, whose settings can be managed with cloudAssistant. Consumption of devices connected to these inputs cannot exceed 250mA.
- Communication module: The equipment has a GSM / Cat M1 / NB-IoT communication module for connection to the Internet.
- Users: Up to 5000 users managed with cloudAssistant.
- Events: Up to 5000 events may be viewed through cloudAssistant.
- Statistics and information on use: You may use cloudAssistant to view a daily graph of the number of relay activations, accepted and rejected users, open-door and closed-door events, data consumption, and more.
- Light-up signals: The equipment has three LED indicators: “ST”, “NW”, and “IN” to indicate the cloudAssistant connection status.
- Anti-passback
- IP54 (with cable gland IP65)
- Operating temperature -20ºC / +55ºC
- Size (L/W/H) 140 x 220 x 55mm
- BUS-LIN cable length: cable cross-sections 0.22/0.35/0.5 mm2 up to 100/150/200 m, respectively. Category 5 cable.
- Up to 20 proximity readers in the same network using an external power supply (BUS-LIN).
- Complies with the RED-DA directive and EN 18031-1 standard.
Transmitters: GOPRO-MINI | GOPRO2 | GOPRO2-IND | GOPRO4 | MUVPRO2 | MUVPRO4
JCM Proximity readers: EVOPROX | STEELPROX-MOT
JCM Proximity devices: MOTION-TAG | MOTION-CARD | NEXTEVO
JCM Transmitters with proximity: GOEVO-MINI | GOEVO2 | GOEVO4 | MUVEVO2 | MUVEVO4
JCM Hands free transmitters: FREE T | FREE TH
Wiegand Proximity readers/keypads: CP5-RX | CP6-RX | CP1-EM | CP1-MF | Any 3rd party Wiegand reader
Wiegand Proximity Cards & Fobs: PCARD | MFCARD | MFCARD-1K | PFOB-IP | PFOB-MF
Desktop USB reader: DCR-1 | DMCR-1
Software: Cloud Assistant
Optional programmer: ASSISTANT
| Weight | 1.1 kg |
|---|---|
| Dimensions | 140 × 220 × 55 mm |
